Construction of 400/33KV Al Jazzier Grid Station along with associated 400KV LILO from Ras Madraka Wind Farm Grid Station to Shaleem Grid Station

Eighteen (18) months excluding six (6) weeks for mobilization, from 13th October 2025

ZP.EP195

The Project Scope shall consist of:
A. Construction of 400/33kV Al Jazzier Grid Station and all associated works

• New 400/33kV Al Jazzier Grid station shall be constructed on turnkey basis (design, supply, construction, installation, testing and commissioning) on the plot located s in the southern part of Al Wusta governate and is around 120 km to the south of the proposed Ras Madrakah Wind Farm grid station and around 200 km from the Special Economic Zone of Duqm (SEZAD).
• 400kV GIS Grid Station shall be constructed under the scope of this tender within the overall plot identified for 400kV GIS Grid Station at Al Jazzier which including 0Nos of 400kV GIS bays with GIB, 2Nos of 63 MVA,400/33kV Power Transformers with OLTC & RTCC and TMS panel, 400kV, 2 x 50MVAR Reactors for Ras Al Madraka feeders including RMS, 1000kVA,33/0.415kV, ONAN, ZNyn11 Earthing Auxiliary Transformer (2Nos), 33kV GIS switchgear (Bus - A & B) consists of 15Bays, 400kV Control & Relay Panels, 33kV C & R Panels (with BCU), 2Nos. of 33kV, 10MVAr Capacitor bank, SCS system including Cyber Security system, RTU based SCADA system, OLCM System, Telecommunication system, Integrated security system, Fire Protection and Fire Alarm system, Roof Top Solar plant, EOT cranes etc

• Existing 400kV Ras Madraka GS - 400kV Shaleem GS OHL circuits shall be Loop In and Loop out at Al Jazzier 400/33kV Grid station including the construction of Gantry, terminal towers, required angle towers, suspension towers etc.
